Huawei OSN 9800 TNV4S216 16 x STM-N optical interface board

    Tech Support
    Service Commitment
    Steps Shipping
    Customer Satisfacition

Description

TNV4S216 overview

The S216 board is a TDM board. The S216 board can be used on the 9800 equipment to transmit and receive STM-n (n=1, 4, 16, or 64) optical signals.

  • The S216 board converts the received STM-n optical signals into VC4, VC-4-Xc (X=4/16/64) signals and sends VC4, VC-4-Xc (X=4/16/64) signals to the cross-connect side.
  • The S216 board supports OTU1 services.
Valid slots
Device Number of Occupied Slots Physical Slot Logical Slot
OptiX OSN 9800 M24 2 (IU1, IU13), (IU2, IU14), ……, (IU11, IU23), (IU12, IU24) IU1 to IU12
OptiX OSN 9800 U32 Enhanced 1 IU1 to IU32 IU1 to IU32
OptiX OSN 9800 U32 Standard 1 IU1 to IU32 IU1 to IU32
OptiX OSN 9800 U64 Enhanced 1 IU1 to IU64 IU1 to IU64
OptiX OSN 9800 U64 Standard 1 IU1 to IU64 IU1 to IU64
Item
TNV4S216
Basic function The maximum SDH capacity is 2 x 40 Gbit/s. 2 x 8 x STM-n (n = 1, 4, or 16)/2 x 4 x STM-64 optical signals OTU1->ODU1->STM16->VC-4
NOTE:
  • Ports on a TNV4S216 board are classified into two groups: TX1/RX1 to TX8/RX8 and TX9/RX9 to TX16/RX16. The maximum SDH capacity of each group of ports is 40 Gbit/s.
  • If both STM-16 and STM-64 services are received, each port group supports a maximum of two STM-64 services. In this case, the maximum SDH capacity of each port group is 35 Gbit/s (2 x 10Gbit/s + 6 x 2.5 Gbit/s).
  • There is no limit on the numbers of STM-16 services and STM-1/STM-4 services that can be received or transmitted concurrently.
  • There is no limit on the numbers of STM-64 services and STM-1/STM-4 services that can be received or transmitted concurrently.
Service processing VC-12, VC-3, VC-4, VC-4-4c, VC-4-16c, VC-4-64c
Overhead processing
  • OTU1 layer: supports SM overhead processing.
  • ODU1 layer: supports PM and TCM overhead processing, and non-intrusive monitoring of PM and TCM overheads.
  • Processes the section overheads of STM-64/STM-16/STM-4/STM-1 signals.
  • Supports the transparent transmission and termination of the path overheads.
  • Sets and queries J0, J1, and C2 bytes.
  • Supports ECC communication.
  • Supports DCC transparent transmission for a maximum of any sixteen ports. The bytes that are transparently transmitted are D1–D3 and D4–D12.
NOTE:
Deleting the logical port that accesses STM-n (n = 1, 4, 16, 64) services will interrupt DCN communication at this port.
SDH SNCP Supported
Linear MSP Supports
Ring MSP
  • Supports two-fiber bidirectional ring MSP
  • Supports four-fiber bidirectional ring MSP
SDH ASON Supported
ALS Supported
Physical clock Supports SDH clock synchronization.
Outband DCN Supported
PRBS Supported
Channel loopback Supports loopbacks on VC paths.
Port loopback Inloops, outloops
2M ASON Supported
Alarm and performance event monitoring Provides various alarms and performance events, facilitating equipment management and maintenance.

Additional information

Brand

Huawei
Lead Time

3-5 days
Ship From

Shenzhen Warehouse
Item
TNV4S216
Basic function The maximum SDH capacity is 2 x 40 Gbit/s. 2 x 8 x STM-n (n = 1, 4, or 16)/2 x 4 x STM-64 optical signals OTU1->ODU1->STM16->VC-4
NOTE:
  • Ports on a TNV4S216 board are classified into two groups: TX1/RX1 to TX8/RX8 and TX9/RX9 to TX16/RX16. The maximum SDH capacity of each group of ports is 40 Gbit/s.
  • If both STM-16 and STM-64 services are received, each port group supports a maximum of two STM-64 services. In this case, the maximum SDH capacity of each port group is 35 Gbit/s (2 x 10Gbit/s + 6 x 2.5 Gbit/s).
  • There is no limit on the numbers of STM-16 services and STM-1/STM-4 services that can be received or transmitted concurrently.
  • There is no limit on the numbers of STM-64 services and STM-1/STM-4 services that can be received or transmitted concurrently.
Service processing VC-12, VC-3, VC-4, VC-4-4c, VC-4-16c, VC-4-64c
Overhead processing
  • OTU1 layer: supports SM overhead processing.
  • ODU1 layer: supports PM and TCM overhead processing, and non-intrusive monitoring of PM and TCM overheads.
  • Processes the section overheads of STM-64/STM-16/STM-4/STM-1 signals.
  • Supports the transparent transmission and termination of the path overheads.
  • Sets and queries J0, J1, and C2 bytes.
  • Supports ECC communication.
  • Supports DCC transparent transmission for a maximum of any sixteen ports. The bytes that are transparently transmitted are D1–D3 and D4–D12.
NOTE:
Deleting the logical port that accesses STM-n (n = 1, 4, 16, 64) services will interrupt DCN communication at this port.
SDH SNCP Supported
Linear MSP Supports
Ring MSP
  • Supports two-fiber bidirectional ring MSP
  • Supports four-fiber bidirectional ring MSP
SDH ASON Supported
ALS Supported
Physical clock Supports SDH clock synchronization.
Outband DCN Supported
PRBS Supported
Channel loopback Supports loopbacks on VC paths.
Port loopback Inloops, outloops
2M ASON Supported
Alarm and performance event monitoring Provides various alarms and performance events, facilitating equipment management and maintenance.
