TNV3SXCL overview
TNV3SXCL 80G VC3/VC12 Low Order Universal Cross-Connect Board applied to Huawei OptiX OSN 9800 U64/U32.
To meet ultra-large cross-connect capacity and bandwidth requirements, Huawei presents the OptiX OSN 9800 product series. The OptiX OSN 9800 product series include the OptiX OSN 9800 U64, U32, P18 and universal platform subracks. Applied at the electrical layer, the OptiX OSN 9800 U64 and U32 subracks share boards by using unified software and hardware platforms, and can work with the OptiX OSN 9800 universal platform subrack and P18 subrack, OptiX OSN 8800 platform subrack and T16 subrack, and OptiX OSN 6800 optical subracks in WDM and OTN systems.
The TNV3SXCL board has three variants: TNV3SXCL01, TNV3SXCL06 and TNV3SXCL07. The three variants are interchangeable.
Front panel of the TNV3SXCL board
Front panel of the TNV3SXCL01 board
Front panel of the TNV3SXCL07 board
Valid slots for the TNV3SXCL board in a U64/U32 subrack
| Device | Number of Occupied Slots | Physical Slot | Logical Slot |
|---|---|---|---|
| OptiX OSN 9800 U32 Enhanced | 1 | IU1 to IU32 | IU1 to IU32 |
| OptiX OSN 9800 U32 Standard | 1 | IU1 to IU32 | IU1 to IU32 |
| OptiX OSN 9800 U64 Enhanced | 1 | IU1 to IU64 | IU1 to IU64 |
| OptiX OSN 9800 U64 Standard | 1 | IU1 to IU64 | IU1 to IU64 |
