H3C SR6602-IE Enhanced ICT converged gateway

    Tech Support
    Service Commitment
    Steps Shipping
    Customer Satisfacition

Description

SR6602-IE overview

Integrating network, compute, and storage capabilities into a single device, H3C SR6602-I AI-powered ICT converged gateways (hereinafter referred to as SR6602-I) enable rapid service delivery and drive business innovations. Compared with traditional gateway products, the SR6602-I has the following benefits:

IT and CT converged—Combines computing and storage capabilities with Comware 9, a cutting-edge containerized network operating system for the cloud era, simplifying network deployment and lowering the total cost of

Powerful computing resources—Provides an Intel Xeon CPU and two drive slots that support RAID setup, allows large memory expansion, and supports using a GPU to deliver AI computing power.

Open architecture—Provides an open operating system platform on which you can deploy services as VMs and containers and interact with OpenStack cloud computing management platforms and Kubernetes management platforms seamlessly.

The SR6602-I can operate in aggregation or convergence mode. In aggregation mode, it operates as an aggregation router to provide tailored services for carriers, governments, power, finance, education, and enterprise customers. The industry-leading containerized network operating system, brand-new hardware platform, and open and programmable designs define the trend for future IT construction and make it a future-oriented data communication solution that can keep up with diversified business expansions in the future.

The SR6602-I AI-powered ICT converged gateways include two models: SR6602-I and SR6602-IE.

Item
SR6602-I
SR6602-IE
CPU 8 cores, 2.5 GHz 12 cores, 2.3 GHz
Forwarding Performance In Service (IMIX) 35Gbps 42Gbps
Built-in WAN port 6 × 10GE SFP+ ports 6 × 10GE SFP+ ports
Built-in LAN port (supports LAN/WAN switching) 14 × 10GE SFP+ ports and 12 × GE RJ-45 ports 14 × 10GE SFP+ ports and 12 × GE RJ-45 ports
FIP slot 1 × FIP slot (supports the FIP-30) 1 × FIP slot (supports the FIP-30)
PCIe slot 1 1
Memory slot 4CH DDR4 RDIMM slots 4CH DDR4 RDIMM slots
Memory size (default/maximum) 8 G/128 G 32 G/128 G
Built-in storage 4 GB 64 GB
External SATA drive slot 2 × 2.5-inch slots 2 × 2.5-inch slots
Internal M.2 SSD slot 1 1
USB 3.0 port 1 1
Console port 1 1
Open-source application management platforms supported KVM, Docker KVM, Docker
Maximum power consumption (aggregation mode/converged mode) 224 W/558 W 239 W/567 W
Power supply redundancy Supported Supported
Removable fan trays 2 2
Power input voltage AC: 100 V to 240 V DC: –48 V to –60 V HVDC: 240 V to 380 V AC: 100 V to 240 V DC: –48 V to –60 V HVDC: 240 V to 380 V
Height 2 RU 2 RU
Dimensions (H × W × D) 88 × 440 × 480 mm (3.46 × 17.32 × 18.90 in) 88 × 440 × 480 mm (3.46 × 17.32 × 18.90 in)
Operating temperature Without drives or GPUs: 0°C to 45°C (32°F to 113°F) With drives or GPUs: 0°C to 40°C (32°F to 104°F)
Ambient humidity 5 % RH to 95% RH, noncondensing
Storage temperature –40°C to +70°C (–40°F to +158°F)
EMC compliance FCC Part 15 (CFR 47) CLASS A ICES-003 CLASS A VCCI-3 CLASS A VCCI-4 CLASS A CISPR 22 CLASS A EN 55022 CLASS A AS/NZS CISPR22 CLASS A CISPR 24 EN 55024 EN 61000-3-2 EN 61000-3-3 EN 61000-6-1 ETSI EN 300 386 EN 301 489-1 EN 301 489-17
Safety compliance UL 60950-1 CAN/CSA C22.2 No 60950-1 IEC 60950-1 EN 60950-1/A11 AS/NZS 60950 EN 60825-1 EN 60825-2 FDA 21 CFR Subchapter J GB 4943
Product ID
Description
RT-SR6602-I H3C SR6602-I ICT converged gateway
RT-SR6602-IE H3C SR6602-I Enhanced ICT converged gateway
HDD-500G-SATA-3G-5.4K-SFF 500GB 2.5-inch SATA HDD
HDD-2T-SATA-6G-5.4K-SFF 2TB 2.5-inch SATA HDD
NS-HDD-1T-SATA-SFF 1TB 2.5-inch SATA HDD
SSD-480G-SATA-M.2 480GB SATA M.2 SSD
UN-DDR4-2666-32G-2Rx4-R 32GB 2Rx4 DDR4-2666P-R memory
UN-DDR4-2933P-64G-2Rx4-R 64GB 2Rx4 DDR4-2933P-R memory
RT-FIP-30 Flexible interface platform module 30
RT-MIC-X-XP4 4-port 10GBASE-R Ethernet optical interface card (SFP+, LC) (MIC-X)
RT-MIC-X-XP2 2-port 10GBASE-R Ethernet optical interface card (SFP+, LC) (MIC-X)
RT-MIC-X-CLP2 2-port OC-3/STM-1 channelized POS optical interface card (SFP, LC) (MIC-X)
RT-MIC-X-CLP4 4-port OC-3/STM-1 channelized POS optical interface card (SFP, LC) (MIC-X)
RT-MIC-X-SP4 4-port OC-3c/STM-1c POS or 1-port OC-12c/STM-4c POS optical interface card (SFP,LC) (MIC-X)
RT-MIC-X-SP8 8-port OC-3c/STM-1c POS optical interface card (SFP,LC) (MIC-X)
RT-MIC-X-ET16 16-port E1/T1 copper interface card (HM96 male connector) (MIC-X)
RT-RISER-FHFL-X16 SR6602-I PCIe Riser Module(FHFL, 1 PCIe X16 Slot)
UN-HBA-H460-B1 12Gb 2 ports SAS HBA card (8 SAS ports)

Additional information

Brand

Huawei
Lead Time

3-5 days
Ship From

Shenzhen Warehouse
Item
SR6602-I
SR6602-IE
CPU 8 cores, 2.5 GHz 12 cores, 2.3 GHz
Forwarding Performance In Service (IMIX) 35Gbps 42Gbps
Built-in WAN port 6 × 10GE SFP+ ports 6 × 10GE SFP+ ports
Built-in LAN port (supports LAN/WAN switching) 14 × 10GE SFP+ ports and 12 × GE RJ-45 ports 14 × 10GE SFP+ ports and 12 × GE RJ-45 ports
FIP slot 1 × FIP slot (supports the FIP-30) 1 × FIP slot (supports the FIP-30)
PCIe slot 1 1
Memory slot 4CH DDR4 RDIMM slots 4CH DDR4 RDIMM slots
Memory size (default/maximum) 8 G/128 G 32 G/128 G
Built-in storage 4 GB 64 GB
External SATA drive slot 2 × 2.5-inch slots 2 × 2.5-inch slots
Internal M.2 SSD slot 1 1
USB 3.0 port 1 1
Console port 1 1
Open-source application management platforms supported KVM, Docker KVM, Docker
Maximum power consumption (aggregation mode/converged mode) 224 W/558 W 239 W/567 W
Power supply redundancy Supported Supported
Removable fan trays 2 2
Power input voltage AC: 100 V to 240 V DC: –48 V to –60 V HVDC: 240 V to 380 V AC: 100 V to 240 V DC: –48 V to –60 V HVDC: 240 V to 380 V
Height 2 RU 2 RU
Dimensions (H × W × D) 88 × 440 × 480 mm (3.46 × 17.32 × 18.90 in) 88 × 440 × 480 mm (3.46 × 17.32 × 18.90 in)
Operating temperature Without drives or GPUs: 0°C to 45°C (32°F to 113°F) With drives or GPUs: 0°C to 40°C (32°F to 104°F)
Ambient humidity 5 % RH to 95% RH, noncondensing
Storage temperature –40°C to +70°C (–40°F to +158°F)
EMC compliance FCC Part 15 (CFR 47) CLASS A ICES-003 CLASS A VCCI-3 CLASS A VCCI-4 CLASS A CISPR 22 CLASS A EN 55022 CLASS A AS/NZS CISPR22 CLASS A CISPR 24 EN 55024 EN 61000-3-2 EN 61000-3-3 EN 61000-6-1 ETSI EN 300 386 EN 301 489-1 EN 301 489-17
Safety compliance UL 60950-1 CAN/CSA C22.2 No 60950-1 IEC 60950-1 EN 60950-1/A11 AS/NZS 60950 EN 60825-1 EN 60825-2 FDA 21 CFR Subchapter J GB 4943
Product ID
Description
RT-SR6602-I H3C SR6602-I ICT converged gateway
RT-SR6602-IE H3C SR6602-I Enhanced ICT converged gateway
HDD-500G-SATA-3G-5.4K-SFF 500GB 2.5-inch SATA HDD
HDD-2T-SATA-6G-5.4K-SFF 2TB 2.5-inch SATA HDD
NS-HDD-1T-SATA-SFF 1TB 2.5-inch SATA HDD
SSD-480G-SATA-M.2 480GB SATA M.2 SSD
UN-DDR4-2666-32G-2Rx4-R 32GB 2Rx4 DDR4-2666P-R memory
UN-DDR4-2933P-64G-2Rx4-R 64GB 2Rx4 DDR4-2933P-R memory
RT-FIP-30 Flexible interface platform module 30
RT-MIC-X-XP4 4-port 10GBASE-R Ethernet optical interface card (SFP+, LC) (MIC-X)
RT-MIC-X-XP2 2-port 10GBASE-R Ethernet optical interface card (SFP+, LC) (MIC-X)
RT-MIC-X-CLP2 2-port OC-3/STM-1 channelized POS optical interface card (SFP, LC) (MIC-X)
RT-MIC-X-CLP4 4-port OC-3/STM-1 channelized POS optical interface card (SFP, LC) (MIC-X)
RT-MIC-X-SP4 4-port OC-3c/STM-1c POS or 1-port OC-12c/STM-4c POS optical interface card (SFP,LC) (MIC-X)
RT-MIC-X-SP8 8-port OC-3c/STM-1c POS optical interface card (SFP,LC) (MIC-X)
RT-MIC-X-ET16 16-port E1/T1 copper interface card (HM96 male connector) (MIC-X)
RT-RISER-FHFL-X16 SR6602-I PCIe Riser Module(FHFL, 1 PCIe X16 Slot)
UN-HBA-H460-B1 12Gb 2 ports SAS HBA card (8 SAS ports)
