Huawei S5732-H48S6Q switch supports 44 1000BASE-X ports, 4 10GE SFP+ optical ports, 6 40GE/100GE QSFP+ optical ports

100GE Uplink Switch 40GE Uplink Switch 48 Ports Switch GE Switch Lan Access Switch

Tech Support

Service Commitment

Steps Shipping

Customer Satisfacition

Description

S5732-H48S6Q Overview

Huawei S5732-H48S6Q switch comes with 44 1000BASE-X ports, 4 10GE SFP+ optical ports, 6 40GE/100GE QSFP+ optical ports

The Huawei Cloud Engine S5732-H series switches are the next-generation enhanced all-optical Ethernet switches developed by Huawei. The Cloud Engine S5732-H builds on Huawei’s unified Versatile Routing Platform (VRP) and boasts various IDN features.

Telecomate.com provides a full range of Huawei switch series, if you have any demands, please contact: csd@telecomate.com

S5732-H48S6Q Quick Spec

44 1000BASE-X ports

4 10GE SFP+ optical ports

6 40GE/100GE QSFP+ optical ports

Forwarding performance is 486/558 MPPS

Switching capacity is 2.4 Tbps/24 Tbps

S5732-H48S6Q appearance and structure

1	Forty-eight 1000BASE-X ports eSFP-GE-SX-MM850 eSFP-GE-ZX100-SM1550 LE2MGSC40DE0 LE2MGSC40ED0	9	One PNP button
2	Four 10GE SFP+ ports OMXD30000 OSX010000 OSX040N01 SFP-10G-ZR SFP-10G-USR	10	Fan module slot 1
3	Six 40GE/100GE QSFP+ optical ports QSFP-40G-eSR4 QSFP-40G-iSR4 QSFP-40G-eSDLC-PAM QSFP-40G-LR4 QSFP-40G-SDLC-PAM	11	Fan module slot 2
4	Ground screw	12	Fan module slot 3
5	SSD card slot	13	Fan module slot 4
6	One ETH management port	14	Power module slot 1
7	One USB port	15	Power module slot 1

Item	S5732- H48S6Q
Fixed ports	48 1000BASE-X ports, 4 10GE SFP+ optical ports, 6 40GE/100GE QSFP+ optical ports
Memory (RAM)	4 GB
Flash	2 GB in total. To view the available flash memory size, run the display version command.
Mean time between failures (MTBF)	56.87 years
Mean time to repair (MTTR)	2 hours
Availability	> 0.99999
Power supply surge protection	Using AC power modules: ±6 kV in differential mode, ±6 kV in common mode; Using DC power modules: ±2 kV in differential mode, ±4 kV in common mode
Rated voltage range	AC input: 100 V AC to 240 V AC, 50/60 Hz; High-Voltage DC input: 240 V DC; DC input: -48 V DC to -60 V DC
Maximum voltage range	AC input: 90 V AC to 290 V AC, 45 Hz to 65 Hz; High-Voltage DC input: 190 V DC to 290 V DC; DC input: -38.4 V DC to -72 V DC
Maximum power consumption (100% throughput, full speed of fans)	255 W
Typical power consumption (30% of traffic load, tested according to ATIS standard)	142 W
Operating temperature	-5°C to +45°C (23°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.)
Storage temperature	-40°C to +70°C (-40°F to +158°F)
Relative humidity	5% to 95% (non-condensing)
Dimensions (W x D x H)	442 mm x 420 mm x 43.6 mm
Weight (with packaging)	9.2 kg (20.28 lb)

Weight	9.0000 kg
Dimensions	43.6000 × 44.2000 × 44.6000 cm
Campus Switch	S5732-H
Brand	Huawei
Lead Time	3-5 days
Ship From	Shenzhen Warehouse

Item	S5732- H48S6Q
Fixed ports	48 1000BASE-X ports, 4 10GE SFP+ optical ports, 6 40GE/100GE QSFP+ optical ports
Memory (RAM)	4 GB
Flash	2 GB in total. To view the available flash memory size, run the display version command.
Mean time between failures (MTBF)	56.87 years
Mean time to repair (MTTR)	2 hours
Availability	> 0.99999
Power supply surge protection	Using AC power modules: ±6 kV in differential mode, ±6 kV in common mode; Using DC power modules: ±2 kV in differential mode, ±4 kV in common mode
Rated voltage range	AC input: 100 V AC to 240 V AC, 50/60 Hz; High-Voltage DC input: 240 V DC; DC input: -48 V DC to -60 V DC
Maximum voltage range	AC input: 90 V AC to 290 V AC, 45 Hz to 65 Hz; High-Voltage DC input: 190 V DC to 290 V DC; DC input: -38.4 V DC to -72 V DC
Maximum power consumption (100% throughput, full speed of fans)	255 W
Typical power consumption (30% of traffic load, tested according to ATIS standard)	142 W
Operating temperature	-5°C to +45°C (23°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.)
Storage temperature	-40°C to +70°C (-40°F to +158°F)
Relative humidity	5% to 95% (non-condensing)
Dimensions (W x D x H)	442 mm x 420 mm x 43.6 mm
Weight (with packaging)	9.2 kg (20.28 lb)
