ME60 ME0M0LEXFB75 with 20-Port 10GBase LAN/WAN-SFP+ Flexible Card E(BP485-E)
ME0M0LEXFB75 Overview
| Item | Details |
|---|---|
| Description | 20-Port 10GBase LAN/WAN-SFP+ Flexible Card E(BP485-E) |
| Part Number | 03034MPS |
| Model | ME0M0LEXFB75 |
| Card type | Flexible Board |
| Silkscreen | BP485-20×10G LAN/WAN-SFP+ -E |
Ports on the ME0M0LEXFB75
| Port | Connector Type | Description | Available Components |
| 0–19 | SFP+ | Interface for inputting and outputting 10GE LAN/WAN optical signals | 10Gbps SFP+ Optical Module
10Gbps SFP+ CWDM Optical Module 10Gbps SFP+ BIDI Optical Module 10Gbps SFP+ DWDM Optical Module |
| Item | ME0M0LEXFB75 |
| Basic function | Provides twenty 10GE interfaces for line-rate transmitting and receiving. |
| Reliability and availability | Hot swappable. |
| Restrictions and remarks | The 10G interfaces working in WAN mode support only the master clock mode and do not support the slave clock mode. |
| Breakout supported | No |
| Interface rate auto-sensing supported | No |
| FlexE supported | No |
| Dimensions without packaging (H x W x D) [mm(in.)] | 37.2 mm x 178.7 mm x 193.3 mm (1.46 in. x 7.04 in. x 7.61 in.) |
| Dimensions with packaging (H x W x D) [mm(in.)] | 95 mm x 290 mm x 370 mm (3.74 in. x 11.42 in. x 14.57 in.) |
| Weight without packaging [kg(lb)] | 1.0 kg (2.2 lb) |
| Weight with packaging [kg(lb)] | 1.5 kg (3.31 lb) |
| Typical power consumption [W] | 73.8 W |
| Typical heat dissipation [BTU/hour] | 239.37 BTU/hour |
| Long-term operating temperature [°C(°F)] | 0°C to 45°C (32°F to 113°F) |
| Short-term operating temperature [°C(°F)] | –5°C to +55°C (23°F to 131°F) |
| Brand | Huawei |
|---|---|
| Lead Time | 3-5 days |
| Ship From | Shenzhen Warehouse |
| Item | ME0M0LEXFB75 |
| Basic function | Provides twenty 10GE interfaces for line-rate transmitting and receiving. |
| Reliability and availability | Hot swappable. |
| Restrictions and remarks | The 10G interfaces working in WAN mode support only the master clock mode and do not support the slave clock mode. |
| Breakout supported | No |
| Interface rate auto-sensing supported | No |
| FlexE supported | No |
| Dimensions without packaging (H x W x D) [mm(in.)] | 37.2 mm x 178.7 mm x 193.3 mm (1.46 in. x 7.04 in. x 7.61 in.) |
| Dimensions with packaging (H x W x D) [mm(in.)] | 95 mm x 290 mm x 370 mm (3.74 in. x 11.42 in. x 14.57 in.) |
| Weight without packaging [kg(lb)] | 1.0 kg (2.2 lb) |
| Weight with packaging [kg(lb)] | 1.5 kg (3.31 lb) |
| Typical power consumption [W] | 73.8 W |
| Typical heat dissipation [BTU/hour] | 239.37 BTU/hour |
| Long-term operating temperature [°C(°F)] | 0°C to 45°C (32°F to 113°F) |
| Short-term operating temperature [°C(°F)] | –5°C to +55°C (23°F to 131°F) |
