M832 congfigure with 1GE+3FE+USB

    Tech Support
    Service Commitment
    Steps Shipping
    Customer Satisfacition

Description

M832 Overview

M832 Optical Network Terminal (ONT) an advanced solution designed to enhance your network connectivity experience. TR069 Manageable, Huawei / ZTE / Nokia OLT Fully Compatible, Easy to Manage, Fast to Connect – Gigabit Routing ONT M832 with 232 Chipset.

The M832 provides 1GE+3FE+USB.



Supported service：
VoIP, Internet
VLAN: 802.1Q, 802.1P, 802.1ad
MAC address table: 1k
L3 function: DHCP server/Client/Relay,NAT
VoIP: SIP/H.248, G.711/G.729, T.30/T.38
Management: Web UI,TR069

Device Parameters
Ports 1GE+3FE+USB
Indicators Power/Pon/Los/Internet/Lan1/Lan2/Lan3/Lan4
System power supply 12V DC, 1 A
Power adapter input 100–240V AC, 50–60Hz
Operating temperature 0°C to +40°C
Operating humidity 5%RH to 95%RH (non-condensing)
Weight About 300g
Dimensions (HxWxD) 170mm*120mm*32mm

Interface Parameters
Optical Port 1xGPON interface (SC/UPC)
Class B+
Receiver sensitivity: -27dBm
Wavelengths: US 1310nm, DS 1490nm
Transmission Distance: 0 ~ 20km
Transmit rate: 2.488Gbps downstream; 1.244Gbps upstream
Ethernet Port 1:1 VLAN / N:1 VLAN/VLAN
MAC limitation/learning
QinQ VLAN

Additional information

Lead Time

3-5 days
Ship From

Shenzhen Warehouse
Device Parameters
Ports 1GE+3FE+USB
Indicators Power/Pon/Los/Internet/Lan1/Lan2/Lan3/Lan4
System power supply 12V DC, 1 A
Power adapter input 100–240V AC, 50–60Hz
Operating temperature 0°C to +40°C
Operating humidity 5%RH to 95%RH (non-condensing)
Weight About 300g
Dimensions (HxWxD) 170mm*120mm*32mm

Interface Parameters
Optical Port 1xGPON interface (SC/UPC)
Class B+
Receiver sensitivity: -27dBm
Wavelengths: US 1310nm, DS 1490nm
Transmission Distance: 0 ~ 20km
Transmit rate: 2.488Gbps downstream; 1.244Gbps upstream
Ethernet Port 1:1 VLAN / N:1 VLAN/VLAN
MAC limitation/learning
QinQ VLAN
