Description
LST7C06HX6E0 overview
LST7C06HX6E0 Huawei S12700E switch 6-Port 100GE QSFP28 Interface Card (X6E, QSFP28)
Switch chassis and software versions matching the card (S12700)
| Card Name | S12700 Chassis |
|---|---|
| LST7C06HX6E0 | Not supported |
Switch chassis and software versions matching the card (S12700E)
| Card Name | S12700E Chassis |
|---|---|
| LST7C06HX6E0 | Supported in V200R019C00 and later versions |
This card can be installed in:
Slots 01 to 04 in an S12700E-4 chassis.
Slots 01 to 08 in an S12700E-8 chassis.
Slots 01 to 12 in an S12700E-12 chassis.
Front Panel
| 1 | Six 100GE optical ports to transmit and receive service traffic at 40 Gbit/s or 100 Gbit/s |
100GE optical port
Attributes of a 100GE optical port
|
Attribute |
Description |
|---|---|
|
Connector type |
QSFP28 |
|
Optical port attributes |
Depend on the QSFP28 – QSFP28 high-speed cable (1 m, 3 m), 40GE QSFP+ Optical Modules, 100GE QSFP28 Optical Modules or QSFP+ or QSFP28 AOC cable used. |
|
Applicable cable |
QSFP+ optical module and LC optical fiber QSFP+ optical module and MPO optical fiber (MPO-MPO or MPO-4*DLC optical fiber) QSFP+ AOC cable (QSFP+ to QSFP+ or QSFP+ to 4*SFP+) QSFP28 optical module and LC optical fiber QSFP28 optical module and MPO optical fiber (MPO-MPO or MPO-4*DLC optical fiber) QSFP28 high-speed copper cable (1 m or 3 m, can only be used as a CSS cable) QSFP28 AOC cable |
