Categories:ZTE ZXA10 C600 Series

GFCH RC0 C+

Name: GFCH RC0 C+
SKU: GFCH RC0 C+
Rating: 5.00 (3 reviews)

Rated 5.00 out of 5 based on 3 customer ratings

3 Reviews Write a review

SKUGFCH RC0 C+

BrandsZTE

AvailabilityIn Stock

WarrantyUp to 36 months

ZTE ZXA10 C600 C650 C620 16-port XGS-PON & GPON Combo Service Board with C+ Module

Tech Support

Service Commitment

Steps Shipping

Customer Satisfacition

Description

GFCH RC0 is a 16-port XGS-PON & GPON combo subscriber card, which can be applied to ZTE ZXA10 C600/C650/C620 GPON OLT.

ZTE 16-port XGS-PON & GPON Combo service card GFCH
Apply to ZTE ZXA10 C600/C650/C620 GPON OLT
Provides 16-port XGS-PON & GPON access.
XGS-PON supports a maximum split ratio of 1:128.
GPON supports a maximum split ratio of 1:128.
Supports the access of XGS-PON ONUs, XG-PON ONUs and GPON ONUs.
Supports OLS.
Supports the optical module ALS function.
Supports hot swappable.

Item	GFCH RC0 C+
Port	16-port
Interface	XGS-PON & GPON Combo
Function	XGS-PON & GPON service access
Specification	XGS-PON & GPON Combo SFP+ interface, with built-in internal multiplexing, SC/UPC optical connector
Modules of the XG-PON Subscriber Card
Management and control module	Configures, controls, and manages the card.
PON MAC module	Implements all the functions on the GPON layer defined in ITU-T G.984.3 and the XGS-PON layer defined by ITU-T G.989.3 and ITU-T G.987.3.
NP module	Implements data processing on the service layer, including service bandwidth and QoS processing based on service types and user needs to meet the SLA requirements. The data processing function complies with TR156.
Optical module	Provides a GPON optical interface that complies with ITU-T G.984.2 or an XGS-PON optical interface that complies with ITU-T G.9807.
Clock module	Processes the system clock in compliance with ITU-T G.8262, G.8264, and G.781.
Device Specifications
Weight	1.65 kg
Dimensions (L x H x W)	393.1 mm × 23.9 mm × 214 mm

Brand	ZTE
Lead Time	3-5 days
Ship From	Shenzhen Warehouse

Item	GFCH RC0 C+
Port	16-port
Interface	XGS-PON & GPON Combo
Function	XGS-PON & GPON service access
Specification	XGS-PON & GPON Combo SFP+ interface, with built-in internal multiplexing, SC/UPC optical connector
Modules of the XG-PON Subscriber Card
Management and control module	Configures, controls, and manages the card.
PON MAC module	Implements all the functions on the GPON layer defined in ITU-T G.984.3 and the XGS-PON layer defined by ITU-T G.989.3 and ITU-T G.987.3.
NP module	Implements data processing on the service layer, including service bandwidth and QoS processing based on service types and user needs to meet the SLA requirements. The data processing function complies with TR156.
Optical module	Provides a GPON optical interface that complies with ITU-T G.984.2 or an XGS-PON optical interface that complies with ITU-T G.9807.
Clock module	Processes the system clock in compliance with ITU-T G.8262, G.8264, and G.781.
Device Specifications
Weight	1.65 kg
Dimensions (L x H x W)	393.1 mm × 23.9 mm × 214 mm
