Categories:Alcatel&Lucent ONT

G-140W-ME

Name: G-140W-ME
SKU: 2010686
Rating: 5.00 (1 reviews)

Rated 5.00 out of 5 based on 1 customer rating

1 Review Write a review

SKU2010686

BrandsALCATEL & LUCENT

AvailabilityIn Stock

WarrantyUp to 36 months

Nokia G-140W-ME GPON Terminal supports 4*GE+1*POTS+2*USB+2.4G/5G WIFI, Huawei OLT Compatible

Tech Support

Service Commitment

Steps Shipping

Customer Satisfacition

Description

G-140W-ME overview

GPON ONT, 4*GE+1*POTS+2*USB, with 2.4G/5G WiFi

ENG firmware

Antenna Gain: 3dB

Connector type SC/UPC

Can be configured by OLT or Web or NMS

Routing function supported

802.11ac supported

IPv4&IPv6 supported

Specification
Working environment	Operating temperature: 0ºC to 40ºC
Working environment	Environment humidity: 5% to 95% (noncondensing)
Typical power consumption	8 W
Power specifications	Power adapter input: 100 to 240 V AC, 50–60 Hz
Power specifications	System power supply: 12 VDC,1.5 A
WLAN	802.11ac
Support IPv4 or IPv6	IPv4 and IPv6
Network-side Port	GPON
User-side Ports	1 x POTS + 4 x GE + 2.4G/5G Wi-Fi + 2 x USB
Indicators	POWER/PON/LOS/TEL/LAN/WLAN/WPS/USB
Dimensions (length x width x height)	170 mm x 137 mm x 32mm
Weight	<1kg

Brand	ALCATEL & LUCENT
Lead Time	3-5 days
Ship From	Shenzhen Warehouse

Specification
Working environment	Operating temperature: 0ºC to 40ºC
Working environment	Environment humidity: 5% to 95% (noncondensing)
Typical power consumption	8 W
Power specifications	Power adapter input: 100 to 240 V AC, 50–60 Hz
Power specifications	System power supply: 12 VDC,1.5 A
WLAN	802.11ac
Support IPv4 or IPv6	IPv4 and IPv6
Network-side Port	GPON
User-side Ports	1 x POTS + 4 x GE + 2.4G/5G Wi-Fi + 2 x USB
Indicators	POWER/PON/LOS/TEL/LAN/WLAN/WPS/USB
Dimensions (length x width x height)	170 mm x 137 mm x 32mm
Weight	<1kg
