Categories:CloudEngine 8800 Series

CE8860-4C-EI

Rated 5.00 out of 5 based on 1 customer rating

1 Review Write a review

PN02350SUK

AvailabilityIn Stock

WarrantyUp to 36 months

Huawei CE8860-4C-EI switch with 32*100GE QSFP28, 4*200GE QSFP56, Without Fan and Power Modules

Tech Support

Service Commitment

Steps Shipping

Customer Satisfacition

Description

CE8860-4C-EI overview

The CloudEngine 8800 series is a next-generation high-performance, high-density, low-latency modular Ethernet switch designed for data centers. It works seamlessly with Huawei’s CloudEngine 16800, 6800, and 5800 switches to build an elastic, simple, open, and secure cloud data center network.

With high-density 400GE/200GE/100GE/40GE/25GE/10GE ports, CloudEngine 8800 supports advanced data center features and high-performance stacking, making it ideal for core or aggregation layers in data centers and campus networks.

Item	Details
Description	CE8860-4C-EI Mainframe (With 4 Subcard Slots, Without FAN Box and Power Module)
Part Number	02350SUK
Model	CE8860-4C-EI

CE8860-4C-EI Appearance

1	Ground screw	2	Two ETH management ports (RJ45)
3	ESN and MAC address label	4	Console port
5	USB port	6	Mini USB port
7	Fan slot 1 Applicable fan modules: FAN-180A series fan modules	8	Fan slot 2 Applicable fan modules: FAN-180A series fan modules
9	Power supply slot 1 Applicable power modules: 1200 W AC&240 V DC power module 1200 W high-voltage DC power module 1200 W DC power module	10	Power supply slot 2 Applicable power modules: 1200 W AC&240 V DC power module 1200 W high-voltage DC power module 1200 W DC power module
11	Extended card slot 1 Applicable cards: CE88-D8CQ CE88-D16Q CE88-D24T2CQ CE88-D24S2CQ CE88-D24S2CQ-U	12	Extended card slot 2 Applicable cards: CE88-D8CQ CE88-D16Q CE88-D24T2CQ CE88-D24S2CQ CE88-D24S2CQ-U
13	Extended card slot 3 Applicable cards: CE88-D8CQ CE88-D16Q CE88-D24T2CQ CE88-D24S2CQ CE88-D24S2CQ-U	14	Extended card slot 4 Applicable cards: CE88-D8CQ CE88-D16Q CE88-D24T2CQ CE88-D24S2CQ CE88-D24S2CQ-U
15	Mounting holes for mounting brackets	–	–

Item		CE8860-4C-EI
Environment parameters	Temperature	Operating temperature: 0°C to 40°C (32°F to 104°F) at altitude of 0-1800 m (0-5906 ft.) NOTE: When the altitude is 1800-5000 m (5096-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Storage temperature: -40°C to +70°C (-40°F to +158°F)
	Relative humidity	5% RH to 95% RH, noncondensing
	Altitude	< 5000 m (16404 ft.)
	Noise (sound pressure, 27°C)	Back-to-front airflow: < 58 dBA Front-to-back airflow: < 56 dBA
Power specifications	Power source type	AC/DC/high-voltage DC
	AC power input	Rated input voltage range: 100 V AC to 130 V AC/200 V AC to 240 V AC, 50/60 Hz Maximum input voltage range: 90 V AC to 290 V AC, 47 Hz to 63 Hz
	DC power input	Rated voltage range: -48 V DC to -60 V DC Maximum voltage range: -38.4 V DC to -72 V DC
	High-voltage DC power input	Rated voltage of 240 V high-voltage DC power input: 240 V DC Maximum voltage range of 240 V high-voltage DC power input: 188 V DC to 290 V DC Rated voltage range of 380 V high-voltage DC power input: 240 V DC to 380 V DC Maximum voltage range of 380 V high-voltage DC power input: 188 V DC to 400 V DC
	Rated input current	1200 W AC&240 V DC power module (PAC-1K2WA series): 10 A (100 V AC to 130 V AC)/8 A (200 V AC to 240 V AC)/8 A (240 V DC) 1200 W high-voltage DC power module (PHD-1K2WA series): 8 A (240 V DC to 380 V DC) 1200 W DC power (PDC-1K2WA series): 38 A (-48 V DC to -60 V DC)
Chassis power consumption	Maximum power consumption	Fully configured with four CE88-D8CQ cards: 625 W Fully configured with four CE88-D16Q cards: 585 W Fully configured with four CE88-D24T2CQ cards: 750 W Fully configured with four CE88-D24S2CQ cards: 602 W Fully configured with four CE88-D24S2CQ-U cards: 718 W
Chassis power consumption	Typical power consumption	Fully configured with four CE88-D8CQ cards: 355 W (100% throughput, QSFP28 cables on 32 ports, double power modules) Fully configured with four CE88-D16Q cards: 340 W (100% throughput, QSFP+ cables on 64 ports, double power modules) Fully configured with four CE88-D24T2CQ cards: 522 W (100% throughput, 3 m Ethernet cables on 96 ports and QSFP28 cables on 8 ports, double power modules) Fully configured with four CE88-D24S2CQ cards: 399 W (100% throughput, SFP28 cables on 96 ports and QSFP28 cables on 8 ports, double power modules) Fully configured with four CE88-D24S2CQ-U cards: 505 W (100% throughput, SFP28 cables on 96 ports and QSFP28 cables on 8 ports, double power modules)
Chassis heat dissipation	Maximum heat dissipation	Fully configured with four CE88-D8CQ cards: 2134 BTU/hr Fully configured with four CE88-D16Q cards: 1998 BTU/hr Fully configured with four CE88-D24T2CQ cards: 2561 BTU/hr Fully configured with four CE88-D24S2CQ cards: 2056 BTU/hr Fully configured with four CE88-D24S2CQ-U cards: 2450 BTU/hr
Chassis heat dissipation	Typical heat dissipation	Fully configured with four CE88-D8CQ cards: 1212 BTU/hr (100% throughput, QSFP28 cables on 32 ports, double power modules) Fully configured with four CE88-D16Q cards: 1161 BTU/hr (100% throughput, QSFP+ cables on 64 ports, double power modules) Fully configured with four CE88-D24T2CQ cards: 1783 BTU/hr (100% throughput, 3 m Ethernet cables on 96 ports and QSFP28 cables on 8 ports, double power modules) Fully configured with four CE88-D24S2CQ cards: 1363 BTU/hr (100% throughput, SFP28 cables on 96 ports and QSFP28 cables on 8 ports, double power modules) Fully configured with four CE88-D24S2CQ-U cards: 1723 BTU/hr (100% throughput, SFP28 cables on 96 ports and QSFP28 cables on 8 ports, double power modules)
Surge protection		Power module: AC: 4 kV in common mode and 2.5 kV in differential mode DC: 4 kV in common mode and 2 kV in differential mode
Heat dissipation	Heat dissipation mode	Air cooling
Heat dissipation	Airflow	Front-to-back or back-to-front, which is determined by features of fan modules and power modules
Reliability and availability	Power module backup	1+1 backup
	Fan module backup	Two fan modules, working in 1+1 backup mode when the temperature is below 35°C
	Hot swap	Supported by all power modules and fan modules
	Mean time between failures (MTBF)	40.88 years
	Mean time to repair (MTTR)	1.75 hours
	Availability	0.99999511530
Technical specifications	Processor	1.5 GHz, quad-core
	DRAM Memory	4 GB
	NOR Flash	16 MB
	NAND Flash	1 GB
Stack	Service port supporting the stack function	See the description of ports on each card.
Certification		Safety standards compliance EMC standards compliance Environmental standards compliance

Item		CE8860-4C-EI
Environment parameters	Temperature	Operating temperature: 0°C to 40°C (32°F to 104°F) at altitude of 0-1800 m (0-5906 ft.) NOTE: When the altitude is 1800-5000 m (5096-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Storage temperature: -40°C to +70°C (-40°F to +158°F)
	Relative humidity	5% RH to 95% RH, noncondensing
	Altitude	< 5000 m (16404 ft.)
	Noise (sound pressure, 27°C)	Back-to-front airflow: < 58 dBA Front-to-back airflow: < 56 dBA
Power specifications	Power source type	AC/DC/high-voltage DC
	AC power input	Rated input voltage range: 100 V AC to 130 V AC/200 V AC to 240 V AC, 50/60 Hz Maximum input voltage range: 90 V AC to 290 V AC, 47 Hz to 63 Hz
	DC power input	Rated voltage range: -48 V DC to -60 V DC Maximum voltage range: -38.4 V DC to -72 V DC
	High-voltage DC power input	Rated voltage of 240 V high-voltage DC power input: 240 V DC Maximum voltage range of 240 V high-voltage DC power input: 188 V DC to 290 V DC Rated voltage range of 380 V high-voltage DC power input: 240 V DC to 380 V DC Maximum voltage range of 380 V high-voltage DC power input: 188 V DC to 400 V DC
	Rated input current	1200 W AC&240 V DC power module (PAC-1K2WA series): 10 A (100 V AC to 130 V AC)/8 A (200 V AC to 240 V AC)/8 A (240 V DC) 1200 W high-voltage DC power module (PHD-1K2WA series): 8 A (240 V DC to 380 V DC) 1200 W DC power (PDC-1K2WA series): 38 A (-48 V DC to -60 V DC)
Chassis power consumption	Maximum power consumption	Fully configured with four CE88-D8CQ cards: 625 W Fully configured with four CE88-D16Q cards: 585 W Fully configured with four CE88-D24T2CQ cards: 750 W Fully configured with four CE88-D24S2CQ cards: 602 W Fully configured with four CE88-D24S2CQ-U cards: 718 W
Chassis power consumption	Typical power consumption	Fully configured with four CE88-D8CQ cards: 355 W (100% throughput, QSFP28 cables on 32 ports, double power modules) Fully configured with four CE88-D16Q cards: 340 W (100% throughput, QSFP+ cables on 64 ports, double power modules) Fully configured with four CE88-D24T2CQ cards: 522 W (100% throughput, 3 m Ethernet cables on 96 ports and QSFP28 cables on 8 ports, double power modules) Fully configured with four CE88-D24S2CQ cards: 399 W (100% throughput, SFP28 cables on 96 ports and QSFP28 cables on 8 ports, double power modules) Fully configured with four CE88-D24S2CQ-U cards: 505 W (100% throughput, SFP28 cables on 96 ports and QSFP28 cables on 8 ports, double power modules)
Chassis heat dissipation	Maximum heat dissipation	Fully configured with four CE88-D8CQ cards: 2134 BTU/hr Fully configured with four CE88-D16Q cards: 1998 BTU/hr Fully configured with four CE88-D24T2CQ cards: 2561 BTU/hr Fully configured with four CE88-D24S2CQ cards: 2056 BTU/hr Fully configured with four CE88-D24S2CQ-U cards: 2450 BTU/hr
Chassis heat dissipation	Typical heat dissipation	Fully configured with four CE88-D8CQ cards: 1212 BTU/hr (100% throughput, QSFP28 cables on 32 ports, double power modules) Fully configured with four CE88-D16Q cards: 1161 BTU/hr (100% throughput, QSFP+ cables on 64 ports, double power modules) Fully configured with four CE88-D24T2CQ cards: 1783 BTU/hr (100% throughput, 3 m Ethernet cables on 96 ports and QSFP28 cables on 8 ports, double power modules) Fully configured with four CE88-D24S2CQ cards: 1363 BTU/hr (100% throughput, SFP28 cables on 96 ports and QSFP28 cables on 8 ports, double power modules) Fully configured with four CE88-D24S2CQ-U cards: 1723 BTU/hr (100% throughput, SFP28 cables on 96 ports and QSFP28 cables on 8 ports, double power modules)
Surge protection		Power module: AC: 4 kV in common mode and 2.5 kV in differential mode DC: 4 kV in common mode and 2 kV in differential mode
Heat dissipation	Heat dissipation mode	Air cooling
Heat dissipation	Airflow	Front-to-back or back-to-front, which is determined by features of fan modules and power modules
Reliability and availability	Power module backup	1+1 backup
	Fan module backup	Two fan modules, working in 1+1 backup mode when the temperature is below 35°C
	Hot swap	Supported by all power modules and fan modules
	Mean time between failures (MTBF)	40.88 years
	Mean time to repair (MTTR)	1.75 hours
	Availability	0.99999511530
Technical specifications	Processor	1.5 GHz, quad-core
	DRAM Memory	4 GB
	NOR Flash	16 MB
	NAND Flash	1 GB
Stack	Service port supporting the stack function	See the description of ports on each card.
Certification		Safety standards compliance EMC standards compliance Environmental standards compliance
