CE8855-32CQ4BQ

Rated 5.00 out of 5 based on 1 customer rating

1 Review Write a review

PN02355KUD

AvailabilityIn Stock

WarrantyUp to 36 months

Huawei CE8855-32CQ4BQ switch with 32*100GE QSFP28, 4*200GE QSFP56, Without Fan and Power Modules

Tech Support

Service Commitment

Steps Shipping

Customer Satisfacition

Description

CE8855-32CQ4BQ overview

The CloudEngine 8800 series is a next-generation high-performance, high-density, low-latency modular Ethernet switch designed for data centers. It works seamlessly with Huawei’s CloudEngine 16800, 6800, and 5800 switches to build an elastic, simple, open, and secure cloud data center network.

With high-density 400GE/200GE/100GE/40GE/25GE/10GE ports, CloudEngine 8800 supports advanced data center features and high-performance stacking, making it ideal for core or aggregation layers in data centers and campus networks.

Item	Details
Description	CE8855-32CQ4BQ Switch(32100GE QSFP28, 4200GE QSFP56, Without Fan and Power Modules)
Part Number	02355KUD
Model	CE8855-32CQ4BQ

CE8855-32CQ4BQ Appearance

1. Ground screw

2. Equipment serial number (ESN) and MAC address

NOTE:

You can scan the code to view the ESN and MAC address of the switch.

3. Console port

4. ETH management port (RJ45)

5. USB port

6. Five Fan slots

7. Two Power supply slots

8. Thirty-two 100GE QSFP28 Ethernet optical ports

9. Four 200GE QSFP56 Ethernet optical ports

10. Three port-side mounting holes for mounting brackets

11. Two middle mounting holes for mounting brackets

12. Equipotential bonding

Ground screws for a ground cable with a two-hole OT terminal

13. Four power-supply-side mounting holes for mounting brackets

–

Item	CE8855-32CQ4BQ
Installation Type	Cabinet installation
Switching capacity	To obtain data of this specification item, see the corresponding datasheet or contact the product sales personnel.
CPU	4-core, 1.4 GHz
Memory	DRAM: 8 GB
NOR Flash	64 MB
SSD Flash	4GB SSD
USB	It can be used for log backup and USB-based deployment. This function is reserved.
Power supply mode	AC pluggable DC pluggable HVDC pluggable
Console port	RJ45
Downlink Service interface	32 x 100G QSFP28 + 4 x 200G QSFP56
Service port supporting the stack function	Reserved function. This function is not enabled.
RTC	Supported
Typical power consumption [W]	378 W (100% traffic load, copper cables on 16 x 100GE + 2 x 200GE ports, normal temperature, dual AC power modules) 417 W (100% traffic load, short-distance optical modules on 16 x 100GE + 2 x 200GE ports, normal temperature, dual AC power modules)
Typical heat dissipation [BTU/hour]	1290 BTU/hour (100% traffic load, copper cables on 16 x 100GE + 2 x 200GE ports, normal temperature, dual AC power modules) 1423 BTU/hour (100% traffic load, short-distance optical modules on 16 x 100GE + 2 x 200GE ports, normal temperature, dual AC power modules)
Static power consumption [W]	331 W
Static heat dissipation [BTU/hour]	1129 BTU/hour
Maximum power consumption [W]	541 W (100% traffic load, short-distance optical modules on 32 x 100GE + 4 x 200GE ports, normal temperature, dual AC power modules) 648 W (100% traffic load, long-distance optical modules on 32 x 100GE + 4 x 200GE ports, high temperature, dual AC power modules)
Maximum heat dissipation [BTU/hour]	1846 BTU/hour (100% traffic load, short-distance optical modules on 32 x 100GE + 4 x 200GE ports, normal temperature, dual AC power modules) 2211 BTU/hour (100% traffic load, long-distance optical modules on 32 x 100GE + 4 x 200GE ports, high temperature, dual AC power modules)
Number of power modules	2
Redundant power supply	1+1 backup
Rated input voltage [V]	1200 W AC&240 V DC power module: 100 V AC to 240 V AC, 50/60 Hz; 240 V DC 1200 W DC power module: –48 V DC to –60 V DC; +48 V DC
Input voltage range [V]	1200 W AC&240 V DC power module: 90 V AC to 290 V AC, 45 Hz to 65 Hz; 190 V DC to 290 V DC 1200 W DC power module: -38.4 V DC to -72 V DC; +38.4 V DC to +72 V DC
Maximum input current [A]	1200 W AC&240 V DC power module: 10 A (100 V AC to 130 V AC); 8 A (200 V AC to 240 V AC); 8 A (240 V DC) 1200 W DC power module: 38 A (–48 V DC to –60 V DC); 38 A (+48 V DC)
Rated output power [W]	1200 W AC&240 V DC power module: 1200 W 1200 W DC power module: 1200 W
Certification	Compliance with safety standards Compliance with EMC standards Compliance with environment and environmental protection standards
Power supply surge protection [kV]	AC: 6 kV in common mode and 6 kV in differential mode DC: 4 kV in common mode and 2 kV in differential mode HVDC: 4 kV in common mode and 2 kV in differential mode
Types of fans	Pluggable
Number of fan modules	5
Redundant fans	The device supports 4+1 backup of fan modules that work in hot standby mode. The system can operate normally for a short time after a single fan module fails. You are advised to replace the faulty fan module immediately.
Heat dissipation mode	Air cooling
Airflow direction	Port-side air intake or port-side air exhaust, depending on the fan modules and power modules that are used. The fan modules and power modules must have the same airflow direction.
Availability	0.999991779
MTBF [year]	27.77 years
Noise at normal temperature (27°C, sound pressure) [dB(A)]	Front-to-back airflow: 52.6 dB(A) on average; maximum: 57.2 dB(A) Back-to-front airflow: 53.6 dB(A) on average; maximum: 59.0 dB(A)
Noise at high temperature (40°C, sound pressure) [dB(A)]	Front-to-back airflow: 71.5 dB(A) on average; maximum: 77.3 dB(A) Back-to-front airflow: 69.7 dB(A) on average; maximum: 75.6 dB(A)
Long-term operating altitude [m (ft.)]	≤ 5000 m (16404 ft.)
Long-term operating relative humidity [RH]	5% RH to 95% RH, non-condensing
Long-term operating temperature [°C (°F)]	0°C to 40°C (32°F to 104°F) at an altitude of 0–1800 m (0–5906 ft.) NOTE: When the altitude is 1800–5000 m (5096–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).
Storage altitude [m (ft.)]	≤ 5000 m (16404 ft.)
Storage relative humidity [RH]	5% RH to 95% RH, non-condensing
Storage temperature [°C (°F)]	-40ºC to +70ºC (-40°F to +158°F)
Dimensions with packaging (H x W x D) [mm (in.)]	185 mm x 650 mm x 550 mm (7.28 in. x 25.59 in. x 21.65 in.)
Dimensions without packaging (H x W x D) [mm (in.)]	Basic dimensions (the depth excludes the parts protruding from the body): 43.6 mm x 442.0 mm x 420.0 mm (1.72 in. x 17.40 in. x 16.54 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 446.5 mm (1.72 in. x 17.40 in. x 17.58 in.)
Weight without packaging [kg (lb)]	6.12 kg (13.49 lb), excluding optical modules, power modules, and fan modules
Weight without packaging (full configuration) [kg (lb)]	8.31 kg (18.32 lb) (including AC power modules and fan modules, excluding optical modules, calculated based on the heaviest model if multiple models are supported)
Weight with packaging [kg (lb)]	10.39 kg (22.91 lb)
Weight with packaging (full configuration) [kg (lb)]	12.58 kg (27.73 lb)
Chassis height [U]	1 U

Item	CE8855-32CQ4BQ
Installation Type	Cabinet installation
Switching capacity	To obtain data of this specification item, see the corresponding datasheet or contact the product sales personnel.
CPU	4-core, 1.4 GHz
Memory	DRAM: 8 GB
NOR Flash	64 MB
SSD Flash	4GB SSD
USB	It can be used for log backup and USB-based deployment. This function is reserved.
Power supply mode	AC pluggable DC pluggable HVDC pluggable
Console port	RJ45
Downlink Service interface	32 x 100G QSFP28 + 4 x 200G QSFP56
Service port supporting the stack function	Reserved function. This function is not enabled.
RTC	Supported
Typical power consumption [W]	378 W (100% traffic load, copper cables on 16 x 100GE + 2 x 200GE ports, normal temperature, dual AC power modules) 417 W (100% traffic load, short-distance optical modules on 16 x 100GE + 2 x 200GE ports, normal temperature, dual AC power modules)
Typical heat dissipation [BTU/hour]	1290 BTU/hour (100% traffic load, copper cables on 16 x 100GE + 2 x 200GE ports, normal temperature, dual AC power modules) 1423 BTU/hour (100% traffic load, short-distance optical modules on 16 x 100GE + 2 x 200GE ports, normal temperature, dual AC power modules)
Static power consumption [W]	331 W
Static heat dissipation [BTU/hour]	1129 BTU/hour
Maximum power consumption [W]	541 W (100% traffic load, short-distance optical modules on 32 x 100GE + 4 x 200GE ports, normal temperature, dual AC power modules) 648 W (100% traffic load, long-distance optical modules on 32 x 100GE + 4 x 200GE ports, high temperature, dual AC power modules)
Maximum heat dissipation [BTU/hour]	1846 BTU/hour (100% traffic load, short-distance optical modules on 32 x 100GE + 4 x 200GE ports, normal temperature, dual AC power modules) 2211 BTU/hour (100% traffic load, long-distance optical modules on 32 x 100GE + 4 x 200GE ports, high temperature, dual AC power modules)
Number of power modules	2
Redundant power supply	1+1 backup
Rated input voltage [V]	1200 W AC&240 V DC power module: 100 V AC to 240 V AC, 50/60 Hz; 240 V DC 1200 W DC power module: –48 V DC to –60 V DC; +48 V DC
Input voltage range [V]	1200 W AC&240 V DC power module: 90 V AC to 290 V AC, 45 Hz to 65 Hz; 190 V DC to 290 V DC 1200 W DC power module: -38.4 V DC to -72 V DC; +38.4 V DC to +72 V DC
Maximum input current [A]	1200 W AC&240 V DC power module: 10 A (100 V AC to 130 V AC); 8 A (200 V AC to 240 V AC); 8 A (240 V DC) 1200 W DC power module: 38 A (–48 V DC to –60 V DC); 38 A (+48 V DC)
Rated output power [W]	1200 W AC&240 V DC power module: 1200 W 1200 W DC power module: 1200 W
Certification	Compliance with safety standards Compliance with EMC standards Compliance with environment and environmental protection standards
Power supply surge protection [kV]	AC: 6 kV in common mode and 6 kV in differential mode DC: 4 kV in common mode and 2 kV in differential mode HVDC: 4 kV in common mode and 2 kV in differential mode
Types of fans	Pluggable
Number of fan modules	5
Redundant fans	The device supports 4+1 backup of fan modules that work in hot standby mode. The system can operate normally for a short time after a single fan module fails. You are advised to replace the faulty fan module immediately.
Heat dissipation mode	Air cooling
Airflow direction	Port-side air intake or port-side air exhaust, depending on the fan modules and power modules that are used. The fan modules and power modules must have the same airflow direction.
Availability	0.999991779
MTBF [year]	27.77 years
Noise at normal temperature (27°C, sound pressure) [dB(A)]	Front-to-back airflow: 52.6 dB(A) on average; maximum: 57.2 dB(A) Back-to-front airflow: 53.6 dB(A) on average; maximum: 59.0 dB(A)
Noise at high temperature (40°C, sound pressure) [dB(A)]	Front-to-back airflow: 71.5 dB(A) on average; maximum: 77.3 dB(A) Back-to-front airflow: 69.7 dB(A) on average; maximum: 75.6 dB(A)
Long-term operating altitude [m (ft.)]	≤ 5000 m (16404 ft.)
Long-term operating relative humidity [RH]	5% RH to 95% RH, non-condensing
Long-term operating temperature [°C (°F)]	0°C to 40°C (32°F to 104°F) at an altitude of 0–1800 m (0–5906 ft.) NOTE: When the altitude is 1800–5000 m (5096–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).
Storage altitude [m (ft.)]	≤ 5000 m (16404 ft.)
Storage relative humidity [RH]	5% RH to 95% RH, non-condensing
Storage temperature [°C (°F)]	-40ºC to +70ºC (-40°F to +158°F)
Dimensions with packaging (H x W x D) [mm (in.)]	185 mm x 650 mm x 550 mm (7.28 in. x 25.59 in. x 21.65 in.)
Dimensions without packaging (H x W x D) [mm (in.)]	Basic dimensions (the depth excludes the parts protruding from the body): 43.6 mm x 442.0 mm x 420.0 mm (1.72 in. x 17.40 in. x 16.54 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 446.5 mm (1.72 in. x 17.40 in. x 17.58 in.)
Weight without packaging [kg (lb)]	6.12 kg (13.49 lb), excluding optical modules, power modules, and fan modules
Weight without packaging (full configuration) [kg (lb)]	8.31 kg (18.32 lb) (including AC power modules and fan modules, excluding optical modules, calculated based on the heaviest model if multiple models are supported)
Weight with packaging [kg (lb)]	10.39 kg (22.91 lb)
Weight with packaging (full configuration) [kg (lb)]	12.58 kg (27.73 lb)
Chassis height [U]	1 U
