Description
ZXR10 5960-32LC-H with 32 40G, 4 10GE/1000Base-x, 4 10GE/1000Base-T
Switching Capacity: 2560Gbps
Categories:ZXR10 5960 Series
5960-32LC-H
BrandsZTE
AvailabilityIn Stock
WarrantyUp to 36 months
ZTE ZXR10 5960-32LC-H with 32 40G, 4 10GE/1000Base-x, 4 10GE/1000Base-T
| Item | ZXR10 5960- 32LC-H | ZXR10 5960- 52DU-H | ZXR10 5960- 72NL-H |
| Dimensions (H×W×D) | 43.6 mm×442 mm×440 mm | ||
| Weight | ≤ 9 kg | ≤ 9 kg | ≤ 9 kg |
| Power Module | AC power supply: 100 V～127 V/200 V～240 V, 50 Hz～60 Hz, support 240 V/336 V high voltage DC input | ||
| DC power supply: -38.4 V to -57.6 V | |||
| Power consumption | Typical power consumption 213 W Maximum power consumption < 298 W | Typical power consumption 170 W Maximum power consumption < 260 W | Typical power consumption 275 W Maximum power consumption < 327 W |
| Reliability |
MTBF：> 300000 hours
MTTR：< 30 minutes |
||
| EMC | ETSI EN 300 386 | ||
| Safety standard |
IEC 60950
EN 60950
EN60825-1
EN60825-2
IEC 60825-1
IEC 60825-2
|
||
| Ambient temperature |
Working temperature -5 ℃ ~ 45 ℃
Storage environment temperature: -40 ℃ ~ 70 ℃
|
||
| Switch capacity |
2560 Gbps
|
1760 Gbps
|
1440 Gbps
|
Additional information
| Brand | ZTE |
|---|---|
| Lead Time | 3-5 days |
| Ship From | Shenzhen Warehouse |
| Item | ZXR10 5960- 32LC-H | ZXR10 5960- 52DU-H | ZXR10 5960- 72NL-H |
| Dimensions (H×W×D) | 43.6 mm×442 mm×440 mm | ||
| Weight | ≤ 9 kg | ≤ 9 kg | ≤ 9 kg |
| Power Module | AC power supply: 100 V～127 V/200 V～240 V, 50 Hz～60 Hz, support 240 V/336 V high voltage DC input | ||
| DC power supply: -38.4 V to -57.6 V | |||
| Power consumption | Typical power consumption 213 W Maximum power consumption < 298 W | Typical power consumption 170 W Maximum power consumption < 260 W | Typical power consumption 275 W Maximum power consumption < 327 W |
| Reliability |
MTBF：> 300000 hours
MTTR：< 30 minutes |
||
| EMC | ETSI EN 300 386 | ||
| Safety standard |
IEC 60950
EN 60950
EN60825-1
EN60825-2
IEC 60825-1
IEC 60825-2
|
||
| Ambient temperature |
Working temperature -5 ℃ ~ 45 ℃
Storage environment temperature: -40 ℃ ~ 70 ℃
|
||
| Switch capacity |
2560 Gbps
|
1760 Gbps
|
1440 Gbps
|
